Displays & Visualization

Standard signal meter for 0/4 ... 20 mA and 0 ... 10 V DC field signals, with ±9999(0) digit display range, 24 V transmitter supply, up to 2 relay outputs and optional analog output.

Standard signal panel meter for process values, measuring 0/4 ... 20 mA, 0 ... 10 V DC or potentiometer inputs with 14.2 mm LED display, transmitter supply and up to 4 alarm outputs.

Set point adjuster for 0/4..20 mA and 0/2..10 V signals, generating isolated analog output values with front-button or external adjustment, programmable range and red 14.2 mm LED display.

Productivity meter for pulse-rate process monitoring, with -99999 ... 99999 digit display range, sec-1, min-1 or h-1 time base, two digital inputs, programmable conversion, hold input and up to four alarm outputs.

Localdisplay for 4..20 mA transmitter signals, loop-powered from the measuring current with 4-digit LCD, freely adjustable display limits, IP65 housing and optional isolated switching output.

Loop-powered display for 4..20 mA standard signals, self-supplied from the measuring current with freely scalable LCD indication, min./max. memory and integrated self-diagnostic.

Digital panel meter for standard voltage and current signals, displaying 0..200 mV, 0..1/2/10/20 V DC, 0..20 mA or 4..20 mA values with red 3½-digit LED and 8..29 V DC supply.

Speed indicator for process control and automation, measuring 0 ... 99999 digit with min-1 time base. Supports PNP, Namur, switch contacts and rotary encoders, with hold input, 14.2 mm LED display and up to four alarm outputs.

Digital process indicator for standard signal processing of 0/4…20mA and 0…10V signals, with TFT color display, galvanically isolated 0/4…20mA or 0…10V output, up to 4 relays and data logger options.

Standard counter for totalizing and preselect counting with 0 ... 999999 digit range, 30 Hz contact input, 15 kHz electronic input, zero-voltage safe count storage and up to 4 relay or transistor outputs.

Universal counter for counting, length measurement, metering and positioning, with -99999 ... 999999 digit range, 2 digital inputs, programmable display conversion, alarm outputs and isolated analog output.

pH and ORP panel meter for pH or ORP measurement, covering -1.00 ... +15.00 pH or -1500 ... +1500 mV with Pt100/Pt1000 temperature compensation, programmable alarms and isolated analog outputs.

Temperature meter for RTD temperature measurement with Pt100 from -100.0..+600.0 °C and Pt1000 from -50.0..+200.0 °C, 14.2 mm red LED display, optional relay alarms and analog output.

Temperature panelmeter for RTD and thermocouple monitoring, with Pt100, Pt1000, Type J, K or S inputs, \pm9999(0) digit display, optional alarm outputs and isolated 0/4...20 mA or 0/2...10 V output.

Temperature controller for PID and process control, with Pt100, thermocouple, 0/1..5 V or 4..20 mA inputs, 2-point, 3-point or continuous control, auto-tuning and optional RS485.

Conductivity meter for liquid purity and concentration measurement, covering 0..2.000(0) μS/cm up to 0..2000 / 200(0) mS/cm with Pt100 or Pt1000 temperature compensation and IP65 field case.
