Rain Instruments

Tipping bucket rain gauges for rainfall monitoring measure 0.1, 0.2 or 0.5 mm/tip with 200 cm2 or 400 cm2 collectors, IP65 protection, optional heating and contact, RS485, SDI-12, 4…20 mA or 0…10 V outputs.

Rain gauge data logger for long-term rainfall trend recording, storing up to 32,255 tipping bucket pulses with 0.050 to 1.599 mm/sample resolution, IP67 protection and isolated RS232C output.

Tipping bucket rain gauge for precipitation monitoring of liquid, mixed or solid precipitation, with 400 cm2 collector area, 0.1, 0.2 or 0.5 mm/tip resolution and contact, analog or SDI-12 outputs.

Precipitation detector for rain and snow detection uses a capacitive heated sensor, -40…+60 °C ambient temperature input, RS485 Modbus-RTU, analog or contact outputs and IP68 protection.

Tipping bucket rain gauge for rainfall monitoring with 0.1, 0.2 or 0.5 mm/tip resolution, NC contact output, 200 cm2 collector area, IP 65 protection and optional 12 Vdc or 24 Vdc heating.

Weighing rain gauge for precipitation monitoring with 400 cm2 collector area, 0.001 mm rainfall resolution, RS485 Modbus-RTU, SDI-12 or pulse output, automatic discharge and optional heating.

Electronic weighing precipitation sensor for rainfall and snow measures liquid, mixed and solid precipitation, with 200 cm² or 400 cm² collecting area, 0–2000 mm/h intensity range, 0.001 mm resolution and automatic draining.
