Conductivity cells

2-electrode ultra-pure water cell with Clamp connection acc. to DIN 32676 or Südmo Aseptic DIN 11850 connection

Conductivity cells for ultrapure water in VARIVENT® inline cases, measuring 0..0.5 µS/cm up to 0..50 µS/cm with C = 0.1, FDA compliant materials, Pt1000 and head or field mounting.

Conductivity flow cell for ultrapure water pipe applications, measuring 0..20 µS/cm up to 0..100 µS/cm with C = 0.5, stainless steel electrodes, Pt1000 and IP65 or IP67 connection.

Conductivity flow cell for drinking water pipe applications, measuring 0..100 µS/cm up to 0..2 mS/cm with C = 0.9, graphite electrodes, Pt1000 and IP65 or IP67 connection.

Conductivity cells for ultrapure water with DIN ISO228 pipe thread, measuring 0..0.5 µS/cm up to 0..50 µS/cm with C = 0.1, Pt1000, CIP-/SIP-capability and LF1653 or LF2653 mounting.

Conductivity cell for pure and ultra-pure water, measuring 0..0.5 μS/cm up to 0..50 μS/cm. Designed for 0..200 °C and max. 20 bar, with Pt1000 temperature measurement and IP67 M12 connection.

Conductivity cell for wells and open systems, measuring 0..20 µS/cm up to 0..500 mS/cm. 4-electrode immersion design for up to 100 m water depth, with Pt1000 temperature measurement and IP67 M12 connection.

Conductivity cell for wells and open systems, measuring 0..20 µS/cm up to 0..500 mS/cm. 4-electrode immersion design with Pt1000 temperature measurement and head or field mounting versions.

4-electrode flow cell for outer pipe diameter from 20 mm up to 63 mm with PVC-U standard fittings for conductivity measurement.

Short description: Conductivity cell for pipe installation, measuring 0..20 µS/cm up to 0..200 mS/cm. 4-electrode screw-in design with G 1/2 A thread, Pt1000 temperature measurement and IP67 8-pole connector.

onductivity cell for pipe installation, measuring 0..20 µS/cm up to 0..500 mS/cm. 4-electrode screw-in design for -10..+120 °C, with Pt1000 temperature measurement and IP67 M12 option.

Conductivity converter for liquid media, measuring conductivity from 0...500mS/cm and temperature from -50..+200°C with RS485 Modbus RTU, IP67 protection and selectable temperature compensation.

Digital conductivity converter for liquid media, measuring 0...200mS/cm and -50..+200°C. 4-electrode cell with G 1/2 A pipe thread, RS485 Modbus RTU, selectable compensation and IP67 protection.

Digital conductivity converter for liquid media, measuring 0...500mS/cm and -50..+200°C. 4-electrode cell with pipe thread DIN ISO 228, RS485 Modbus RTU, selectable compensation and IP67 protection.

Conductivity flow cell for pipe installation in 25-63 mm pipes, measuring 0..100 µS/cm up to 2 mS/cm with C = 1.0 graphite electrodes, integrated Pt1000 and M12x1 IP67 connector.

Conductivity transmitter for liquid monitoring from 1…50,000 µS/cm with Pt1000 temperature measurement, 4-pole graphite electrodes, RS485 Modbus-RTU output and ingress protection (IP68).
