Single Switching Point

A single switching point is the straightforward choice when one defined limit is enough. Single-point float level switches use a magnetic float to actuate a reed contact at the specified position, providing a clear switching signal when the level is reached. This helps you implement reliable minimum or maximum level monitoring, support simple control tasks, and keep operation stable with minimal maintenance effort.

View all products

Product Overview (27)

Level switch for fluid media control - side installation MW3

Level switch for fluid media control with G ¾ A or G 1 A thread, micro switch, 250 V AC and 5 A switching capacity, IP65 protection and brass or stainless steel construction.

Level switch for fluid media control - side installation NW1

Level switch for fluid media monitoring with reed switch, G ¾ A or G 1 A thread, normally open or normally closed contact, max. 230 V AC, 1 A switching current, 50 VA capacity and IP65 protection.

Level switch for fluid media control - side installation NW3

Level switch for fluid media monitoring with reed switch, G ¾ A or G 1 A thread, normally open or normally closed contact, max. 230 V AC, 1 A switching current, 50 VA capacity and IP65 protection.

Level switch for liquid control up to 120 °C - side installation SIMPLE B77

Level switch for lateral liquid control with 1 or 2 SPDT microswitches, adjustable float rod and DN 25 process connection. It supports 10 bar pressure, 120 °C process temperature and IP65 electrical housing.

Level switch for bilge pump operation in ships and boats SIMPLE BILGE

Level switch for bilge pump operation in ships and boats, with RINA Naval and Exia ATEX certification. It uses an AISI-316L magnetic float, SPDT contact, IP68 protection and 5 m or 10 m armored cable.

Modular level switch kit for adjustable tank installation SIMPLE KIT.S1

Modular level switch kit for tank level control with 1 electrical contact, closed cell float, threaded or flanged mounting, DIN 43650 plug, IP65 protection, -30 / +55 °C ambient operation and 105 °C max temperature.

Compact level switch for space-saving tank installation - side installation SIMPLE ML

Compact level switch for tank level control with 1 electrical contact, polypropylene or PVDF versions, SPST or SPDT contact, IP65 protection, 1.5 m or 3 m cable options and 90 °C or 130 °C temperature ratings.

Level switch for OEM liquid level control in compact tanks SIMPLE S1.P12

Level switch for OEM liquid level control with natural polypropylene construction, magnetic float and SPST reed contact. It offers M8x1,25 thread, 500 mm PVC leads, IP65 protection, 4 bar pressure and 90 °C operation.

Adjustable level switch for liquid monitoring in tanks SIMPLE R1

Adjustable level switch for liquid monitoring with SPST or SPDT sealed contact, 500 or 1000 mm rod length, closed cell float, DIN 43650 plug, threaded or flanged mounting, IP65 protection and 105 °C max temperature.

Adjustable level switch for OEM liquid monitoring with SPDT output SIMPLE R1-M.B77

Adjustable level switch for liquid monitoring with SPDT micro-switch, 500 or 1000 mm rod length, closed cell float, DIN 43650-A plug, threaded or flanged mounting, IP65 protection and 90 °C max temperature.

Level switch for fluid media control - side installation SIMPLE RW2

Side-mounted level switch for liquid control with AISI-316 body and float, 1/2" NPT thread, SPST or SPDT reed contact, M12, DIN-43650A or cable gland connection, 5 Bar, 130 °C and IP65/IP67 protection.

Level switch for small tanks with one electrical contact SIMPLE S1

Level switch for small tanks with 1 electrical contact, closed cell float, 100 to 500 mm rod lengths, threaded or flanged mounting, brass, anodized aluminum or PVC connections, DIN 43650 plug and IP65 protection.
