Cables

Reliable connections are essential for accurate measurements and uninterrupted sensor operation. Our cables and connection accessories provide secure power and signal transmission for sensors and instruments, with robust designs suitable for both indoor and outdoor installations. Available in different lengths and configurations, they make it easy to extend, connect and integrate your measurement equipment while maintaining consistent data quality across your monitoring system.

View all products

25 Products

5-pole cable for M12 actuator and sensor connections CPM12-5

Actuator and sensor cable for M12 connections, with 5-pin A-coded female connector, PUR shielded cable in 5 m, 10 m, 25 m or 50 m lengths, 60 V and 4 A rating, and ingress protection (IP67 and IP69K).

12-pole cable with 8-pin M12 connector and open wires CP18

12-pole cable for LPSD18, HD2016 and HD9408.3B, with an 8-pin M12 connector on one end and open wires on the other. Available as 5 m CP18.5 or 10 m CP18.10.

Shielded cable for HD2003 3-axis ultrasonic anemometers CP2003

Shielded cable for HD2003 anemometers, with 26-pole watertight connector, open wires, 8 mm diameter and 5 m or 10 m lengths for CP2003/5 and CP2003/10.

Connection cable for rain detectors CP2013

Connection cable for HD2013.3 rain detectors, with an 8-pole watertight connector on one end and free wires on the other. Available in 5 m and 10 m lengths.

Rain gauge cable for data logger connection CP2013-DB

Rain gauge cable for connecting a rain gauge to the HD2013-DB data logger, with 1 m length, 4-pole M12 female connector on one side and open wires on the other.

PC connecting cable for pyranometer configuration CP24B

PC connecting cable for pyranometer configuration with built-in RS485/USB converter, 5-pole or 8-pole M12 sensor connector and A-type USB connector for the PC.

Serial connection cable for data logger PC connection CP25

Serial connection cable for data logger PC connection with built-in USB/RS232 converter, USB connector on the PC side and 8-pole M12 female connector on the instrument side.

9-pole M23 cable for HD51 anemometers CP51

19-pole M23 cable for HD51 anemometers, with a female connector on one side and open wires on the other. Available in 5 m and 10 m lengths for HD51.3D... series instruments.

19-pole M23 cable for HD52 anemometers CP52

19-pole M23 cable for HD52 anemometers, with a female connector on one side and open wires on the other. Available in 5 m and 10 m lengths.

19-pole M23 female free connector for cable assembly CP52.C

19-pole M23 female free connector for cable assembly and additional field-side connection requirements.

8-pole cable for M12 actuator and sensor connections CPM12-8

8-pole M12 cable for actuator and sensor connections, with A-coded female connector, shielded PUR jacket in 5 m, 10 m, 25 m or 50 m lengths, 30 V and 2 A rating, and ingress protection (IP67 and IP69K).

8-pole cable for SDI-12 or RS485 sensors CPM12-8D

8-pole cable for sensor connection with M12 connector on one end and open wires on the other. For sensors with SDI-12 or RS485 output, available in 5 m and 10 m lengths.

8-pole cable for analog + RS485 sensors CPM12-8DA

5 m or 10 m 8-pole cable for LPPYRHE16ACS, with M12 connector on one end and open wires on the other. For analog + RS485 double output sensor connection.

8-pole connection cable CPM12-8PM

8-pole connection cable for PMsense connections, available in 2 m, 5 m or 10 m lengths, with an 8-pole connector on one end and open wires on the other for customer-side wiring.
