For stable temperature monitoring with a defined probe geometry and secure connection, this Pt100 temperature probe supports clean integration into measurement and logging systems in buildings, labs, and general industry.
The probe uses a Pt100 1/3 DIN sensor and a robust stem design with Ø 14 mm diameter and 140 mm length. A 2 m cable provides practical reach between the measuring point and the device, while the 8-pole M12 connector supports fast connection and reduces wiring effort during installation or service.
For outdoor installations, the probe requires the optional HD9007A-3 protection against solar radiations. This helps ensure the probe is installed as intended when exposed to direct sunlight.
Integrated Pt100 sensor with 1/3 DIN specification for temperature measurement
Probe stem diameter Ø 14 mm with 140 mm length for installation at measurement points
2 m cable terminated with an 8-pole M12 connector for instrument connection
Outdoor installation requires optional HD9007A-3 protection against solar radiations
Designed as a temperature probe for use with compatible measuring instruments and data loggers
