Accurate outdoor air temperature starts with keeping solar radiation away from the sensing element. TP32MTT.03.C measures air temperature using a 4-wire Pt100 sensor and a protective screen designed to reduce radiation influence, helping you capture representative ambient values in weather and environmental monitoring.
The radiation shield uses UV-resistant ASA technopolymer with low thermal conductivity and high reflection. The sensor position inside the screen is designed to prevent it from being directly hit by radiation, supporting stable readings even in sunny conditions.
Installation options support common mounting scenarios. TP32MTT.03.C is supplied with a bracket made of Anticorodal aluminum, powder coated white, and can be fixed on a flat support or on a Ø25...44 mm mast using the appropriate mounting kit. The probe operates from -40...+85 °C, has IP67 protection and is supplied with a 2, 5 or 10 m cable terminated with open wires for flexible connection to your measurement system.
Single probe for air temperature measurement using a 4-wire Pt100 sensor.
Screen is UV-resistant ASA technopolymer with low thermal conductivity and high reflection.
The sensor position inside the screen is designed to prevent direct radiation exposure.
Supplied with 2, 5 or 10 m cable terminated with open wires; TP32MTT.03.C uses a 4-pole cable.
Working temperature is -40...+85 °C with 1/3 DIN sensor class.
Can be installed with HD9007T29.1 bracket on a flat support or with HD9007T29K kit on Ø25...44 mm mast.
