Pt100 immersion probe for liquids and gases up to +400 °C

GTF 35

Pt100 immersion probe for liquids and gases, measuring -50 ... +400 °C with Ø3 mm V4A tube, DIN Class B, AA, A or 1/10 DIN Class B accuracy, and Mini-DIN, M12 or ferruled loose-end connection.
View all variants Product Inquiry

Introduction

Reliable temperature checks in liquids and gases depend on a slim probe that reacts quickly and withstands regular contact with the medium. This Pt100 immersion probe uses a rust-resistant Ø3 mm V4A tube and is designed without a handle for direct integration into measurement setups.

The probe covers -50 ... +400 °C for broad use in liquid and gas temperature measurement. Response behavior is clearly defined, with an approx. 10 s T90 response time in water at 0.4 m/s and approx. 40 s in air at 2 m/s. Users can select DIN Class B, AA, A or 1/10 DIN Class B accuracy, depending on the required measurement quality.

The family offers practical configuration options for different tasks. The standard version has a 150 mm probe length and 1 m PVC cable for -20 ... +70 °C. Other probe and cable lengths are available. A Teflon-covered V4A tube is available for acid and seawater applications up to 200 mm probe length, with a maximum measuring range of -50 ... +250 °C.

Slim immersion design
Ø3 mm V4A tube supports temperature checks in liquids and gases.
Selectable accuracy
Available in DIN Class B, AA, A or 1/10 DIN Class B accuracy.
Defined response
T90 is approx. 10 s in water at 0.4 m/s and approx. 40 s in air at 2 m/s.
Medium protection
Optional Teflon cover suits acid and seawater use up to 250 °C.

Features

Pt100 sensor element

The probe uses a Pt100 sensor element for temperature measurement in liquid and gaseous media.

Probe construction

The immersion probe is built without a handle and uses a rust-resistant V4A tube with Ø3 mm diameter.

Probe length variants

The standard probe length is 150 mm. Other probe lengths are available for different installation depths.

Cable configuration

The standard version has a 1 m PVC cable with a specified cable temperature range of -20 ... +70 °C. Other cable lengths are available.

Connection variants

Versions are available with Mini-DIN plug in 4-wire configuration, 4-pin M12 plug or loose ends with ferrules.

Teflon-covered option

The V4A probe tube can be supplied with a Teflon cover for acid and seawater applications, limited to 200 mm length and -50 ... +250 °C.

Details

Dimensions in mm
