Field measurements can expose dissolved oxygen sensor membranes to contact, impact and damage that can compromise reliable water analysis. GSKA protection hats add a mechanical shield in front of the membrane face, helping protect the sensitive surface during measurements where contact with the substrate may occur.
The design supports protection without blocking the measurement environment. Optimized airflow helps media exchange across the membrane, while the cap prevents direct impact contact. This makes the family well suited for aquaculture applications where bite damage can be a risk, and wastewater applications where mechanical contact or impact may occur.
The family covers different sensor designs: GSKA 36x0 protection hats are intended for electrochemical sensors with a 12 mm diameter and sinking use, while GSKA 532 protection hats are screw-on caps for the 12 mm DX 532 optical sensor.
The protection hat acts as a physical barrier in front of the sensor membrane face and helps prevent direct impact contact during use.
The cap geometry is optimized for airflow, allowing media exchange across the membrane without impeding the measurement environment.
GSKA 36x0 versions are designed for electrochemical sensors with a 12 mm diameter and sinking applications.
GSKA 532 is a screw-on protection hat for the 12 mm DX 532 optical oxygen sensor.
The protection hats are used with dissolved oxygen sensors in water analysis tasks where membrane protection is required, including aquaculture and wastewater applications.
| Materials |
PVC
|
|---|
| Probe Diameter |
12 mm
|
|---|
